Full-Body LED 2FT 4FT High Bay

Full-Body LED 2FT 4FT High Bay

The 2ft & 4ft Size full-body LED high bay series is designed for Indoor and Industrial lighting. Accessories include lenses (clear & diffused), wire-guard kits, surface-mounting kits, pendant-mounting kits, and cable-mounting kits.

• Easy installation in new construction or retrofit.
• Wattages available in 90W(12,600LM), 135W(18,900LM), 180W(25,200LM), & 215W(30,100LM)
• Lumens per Watt are 140LPW
• CCT is available in 4000K or 5000K
• Housing: Die cast aluminum
• 0-10V Dimmable
• Long-life LEDs provide 122,000 hours of operation
• Power factor > 0.90
• Total harmonic distortion < 20%
• Color rendering index > 80
• Painted steel housings are standard
• Chain-mount kits (includes v-hooks and ⅛” thick, 1-meter long chain) are standard
• Flicker-free per IEEE1789-2015 (low risk of adverse effects of flicker at 100% light output level)
• cULus listed for damp locations in ambient temperatures from -20°C to 50°C (-4°F to 122°F)

• Easy installation in new construction or retrofit.
• Wattages available in 265W(37,100LM), 307W(42,980LM), & 425W(60,629)
• Lumens per Watt are 140LPW
• CCT is available in 4000K or 5000K
• Housing: Die cast aluminum
• 0-10V Dimmable
• Long-life LEDs provide 122,000 hours of operation
• Power factor > 0.90
• Total harmonic distortion < 20%
• Color rendering index > 80
• Painted steel housings are standard
• Chain-mount kits (includes v-hooks and ⅛” thick, 1-meter long chain) are standard
• Flicker-free per IEEE1789-2015 (low risk of adverse effects of flicker at 100% light output level)
• cULus listed for damp locations in ambient temperatures from -20°C to 50°C (-4°F to 122°F)

Options

LEDFHB-CRLENS-12X23: Clear lens – 90W, 135W & 180W

LEDFHB-CRLENS-17X23: Clear lens – 215W

LEDFHB-CRLENS-12X45: Clear lens – 265W & 320W

LEDFHB-CRLENS-17X45: Clear lens – 425W

LEDFHB-DIFLENS-12X23: Diffuse lens – 90W, 135W & 180W

LEDFHB-DIFLENS-17X23: Diffuse lens – 215W

LEDFHB-DIFLENS-12X45: Diffuse lens – 265W & 320W

LEDFHB-DIFLENS-17X45: Diffuse lens – 425W

LEDFHB-WG-12X23: Wire-guard kit – 90W, 135W & 180W

LEDFHB-WG-17X23: Wire-guard kit – 215W

LEDFHB-WG-12X45: Wire-guard kit – 265W & 320W

LEDFHB-WG-17X45: Wire-guard kit – 425W

LEDFHB-SMK-12.625WIDE: Surface-mount kit – 90W, 135W, 180W, 265W & 320W

LEDFHB-SMK-17.25WIDE: Surface-mount kit – 215W & 425W

LEDFHB-PMK: Pendant-mount kit – 90W, 135W, 180W, 265W, 320W, & 425W

LEDFHB-PMK8: Pendant-mount kit – 215W

LEDFHB-CMK3: Cable-mounting kit, 3 meters long

LEDFHB-CMK5: Cable-mounting kit, 5 meters long

Warranty

5-Year Manufacturer Limited Warranty

Certifications

DLC Premium, cULus,CE, FCC, RoHS, IP20 Rated
